EA圆形吊装带

EA ROUND SLINGS

产品详情

1.圆形吊装带,zui大负荷可至3000吨,有效长度可至100米,an全系数一般采用7:1 ,6:1。

2.圆形吊装带是采用高强度聚脂工业长丝(PES)制成,内部承载芯采用无极环绕以构成xun环状,外部使用PES织成不受力的套管对承载芯加以保护。

3.吊装带维护非常简易,因撞击而造成损害在吊装作业中是很普遍发生危险的,而EA-A型吊装带在强烈撞击下只会扁平化,所以风险几乎为零。

4.如果吊带严重损坏,将首先是外面的套管破损从而核心的承载芯会暴露出来表示吊装带已经受到损害;在重复的测试中已经显示,如没有可见的外部套管受伤害,则内部到受损害的概率是较小的,同时如果内部的承载丝束已经断裂,它将会透过套管而被发现。

5.如果套管上有小的割伤可以用松弛的胶带加以保护,以免更一步的裂开,但需要仔细检查确定有没有内部的损害才可以继续使用。如果圆形吊装带套管上有大的割伤的话,就需要由我公司来检查是否可以修理和继续使用。


产品介绍

1.Round sling has the maximum load up to3000T,effective length up to 100m safety Factor adopted is normally 7:1,6:1.

2.Round sling is made of high tension Polyester yarn(100%PES),the strands inside are as a form of endless cycle. The outside sleeve is also made of 100%PES,not for the loading,but to protect the strands inside.

3.Round slings are the ideal solution for the safe lifting of loads,whether this is to be at your works,for loading and unloading or for using at a building site. The round slings will protect items being lifted. If the sling is damaged badly,the outside sleeve is breakage,and the inside strands will go out,so the sling can not be used any more. Their sturdy core and a covering layer will guarantee a long serviceable life,even when in continuous use.round slings are also repairable.
